VERTICAL STORAGE (CAD, PDF)

Vertical Storage Plans SM.jpg

Every small shop runs into the same issue at some point.  That issue is material storage!  I developed this Vertical Storage solution to maximize the floor print and take advantage of slanted vertical space allowing for easy access to materials of multiple shapes and sizes.  This includes the PDF assembly document as well as the 3D model and actual nested 2D CAD files ready to cut and assemble!

NOTE:  Please allow 24 hours for me to send you the files!

$12.00

PLANS AND DOCUMENTATION

  • YouTube

DRAG KNIFE (CAD)


I have always wanted to develop my own drag knife to cut cardboard, wood veneer, paper etc... In this video, I 3D print and test a prototype and then mill the final working knife out of aluminum.

The bearings you will need are 1/2" ID X 1.125" OD bearings found here...  VXB Bearings

NOTE:  Please allow 24 hours for me to send you the files!

$5.00

  • YouTube

FIRE~KEG (PLAN SET)


This is a document set for building the Grunblau FIRE~KEG. The digital PDF plans contain the bill of materials, drawings, renderings, and patterns necessary to reproduce my foundry torch and foundry furnace.



NOTE:  Please allow 24 hours for me to send you the files!

$10.00

  • YouTube

FIRE~BASKET (PATTERNS)


I designed a fire basket out of simple angle iron. What I came up with would be very time consuming to layout considering all of the intersecting angles. I decided to try an alternative method. Now you can use these patterns to build your own fire basket too!

NOTE:  Please allow 24 hours for me to send you the files!

$8.00

  • YouTube

SOAP DISH (CAD, CAM)


I provide both the CAD geometry and the Gcode for you to be able to reproduce my soap dish on your own machine!



You will also see that I have included the integrated flip geometry. This is a way I developed in order to simplify the process involved in milling a 2 sided object as the fixture is incorporated into the cut out geometry!

NOTE:  Please allow 24 hours for me to send you the files!

$10.00

  • YouTube

GRUNBLAU MDF3790


This is a full size document set for building the Grunblau MDF3790. The plans contain the bill of materials, drawings, renderings, wiring diagrams, patterns and easy to follow instructions required to reproduce my machine. When you purchase the PDF, you will also receive a full scale pattern sheet that contains all of the patterns nested on a one page PDF for easy printing. Also included is the CAD geometry in as in various formats for CNC processing or as a great jumping off point to develop your own design!

NOTE:  Please allow 24 hours for me to send you the files!

$40.00

  • YouTube

PLATFORM CNC PRODUCTION FILES


I developed the Platform CNC to be everything I wanted in my own shop CNC.  I produced 200+ of these machines for people.  There is still a lot of interest in producing the machine and doing more production runs.  This machine can easily process quarter sheets of plywood in its 30" X 48" X 6" work envelope.  This is all of the production files and documentation for producing your very own Platform CNC as well as the HIWIN rail upgrade I developed to compliment this already extremely robust machine.

NOTE:  Please allow 24 hours for me to send you the files!

 AVAILABLE SOON!
